Effective Date: 09/25/08 Page 9 of 9
ATS Systems
Form
Subject: Ultimate Chuck Install & Training Checklist
Doc. No. FM 9-112
Rev.C
ULTIMATE CNC CHUCK AND LATHE CYLINDER SPECIFICATIONS
FOR THIS INSTALLATION
Chuck Model _____________________ Cylinder Model ______________________________
Max. Chuck piston stroke = __________” Max. Cylinder piston stroke = _______________ ”
Max. Chuck jaw stroke = ____________” Jaw stroke with this Cylinder = _______________” (If
jaw stroke is less than maximum, use half pitch base
jaws as required for hard jaw applications.)
Max. allowable Cylinder pressure = ____________ psi.
Max. Cylinder pull = _______________lbs. at max. pressure.
Max. available machine pressure = _____________ psi.
Max. Chuck drawbar pull = _________ lbs. Cylinder pull at max machine pressure = ___________ lbs.
- If cylinder pull at maximum machine pressure exceeds maximum chuck drawbar pull:
Limit cylinder pressure to __________ psi or damage to chuck will occur.
- If cylinder pull at maximum machine pressue is less than maximum chuck drawbar pull:
With this cylinder at the maximum available machine pressure, the chuck develops _______% of its
maximum possible grip force.
ATS Systems (800) 423-4651
