ATSG AXOD - Ford AXOD;AXODE (AX4 S) 3 rd Roller Clutch; 3 rd Roller Clutch

HOLD
INNER RACE
FREEWHEEL
OUTER RACE
FORD AXOD, AXODE (AX4S)
3RD ROLLER CLUTCH
THE 3RD ROLLER CLUTCH OUTER RACE MUST FREEWHEEL
CLOCKWISE AND LOCK COUNTER CLOCKWISE WHEN THE
3RD ROLLER CLUTCH INNER RACE IS HELD
F
R
L
E
E E
E
W H
Technical Service Information
AUTOMATIC TRANSMISSION SERVICE GROUP
63
Figure 53
Copyright © 2002 ATSG
