ATTO Technology ExpressSAS R608 - Page 32

29
Exhibit 6-3 Connect an H608 or H60F to several different backplane configurations
Mini-SAS
Connector
PHYs Backplane Backplane
Slots
H608 - 2 x4 Backplanes (See example 1.)
J2 0-3 1 1-4
J1 4-7 2 1-4
H608 - 1 x6 Backplane
J2 0-3 1 1-4
J1 4-5 1 5-6
H608 - 1 x8 Backplane
J2 0-3 1 1-4
J1 4-7 1 5-8
H60F – 2 x4 Backplanes
J1 0-3 1 1-4
J2 4-7 2 1-4
J4 n/a n/a n/a
J3 n/a n/a n/a
H60F - 1 x6 Backplanes
J1 0-3 1 1-4
J2 4-5 2 5-6
J4 n/a n/a n/a
J3 n/a n/a n/a
H60F - 1 x4 & 1 x6 Backplanes (See example 3.)
J1 0-3 1 1-4
J2 4-7 2 1-4
J4 8-9 2 5-7
J3 n/a n/a n/a
H6F - 1 x16 Backplane
J1 0-3 1 1-4
J2 4-7 1 5-8
J4 8-11 1 9-12
J3 12-15 1 13-16
(Examples start on page 35)
