28 ATTO Technology Inc. ATTO ExpressSAS Host & RAID Adapter Installation and Operation Manual
Connecting data cables to hard drive backplanes
Exhibit 6-2 Connect an R608 or R60F to several different backplane configurations
Mini-SAS
Connector
PHYs Backplane Backplane
Slots
R608 - 2 x4 Backplanes (See example 1.)
J3 0-3 1 1-4
J2 4-7 2 1-4
R608 - 1 x6 Backplane
J3 0-3 1 1-4
J2 4-5 1 5-6
R608 - 1 x8 Backplane
J3 0-3 1 1-4
J2 4-7 1 5-8
R60F - 1 x4 Backplanes
J1 0-3 1 1-4
J2 n/a n/a n/a
J3 n/a n/a n/a
J4 n/a n/a n/a
R60F - 1 x6 Backplanes
J1 0-3 1 1-4
J2 4-5 2 5-6
J3 n/a n/a n/a
J4 n/a n/a n/a
R60F - 1 x4 & 1 x6 Backplanes (See example 3.)
J1 0-3 1 1-4
J2 4-7 2 1-4
J3 8-9 2 5-7
J4 n/a n/a n/a
R60F - 1 x16 Backplane
J1 0-3 1 1-4
J2 4-7 1 5-8
J3 8-11 1 9-12
J4 12-15 1 13-16
(Examples start on page 35)
