TECHNICAL SPECIFICATION SHEET
Motor type 1
1000W 36V
Motor type 2
1300W 48V
MAX. Power output 1000W36V
1.88KW/1500RPM
MAX. Power output 1300W48V
3.30KW/1520RPM
Max torque (1000W motor)
10.2Nm /1500RPM
Max torque (1300W motor)
18.5 Nm/1520RPM
Battery
3 x 12V 12A lead acid battery for 36V 1000W
48V10A / 48V 13A lithium battery for 48V1300W
Charger INPUT for 36V lead acid battery
100-240V/50-60 Hz/1.5A
Charger OUTPUT for 36V lead acid battery
44.0V-1.5A
Charger INPUT for 48V lithium battery
100-240V/47-63 Hz/2.0A
Charger OUTPUT for 48V lithium battery
54.6V-2.0A
Non-load input current
≤115mA
Maximum motor current controller output
35A±1.0A/1000W36V
40A±1.0A/1300W48V,
Transmission
Chain drive
Front suspension
double mechanical damper
Rear suspension
mono shock absorber
Tyre
Tubelss tyre,front 14*4.10-6, rear 14.00 x 5-6 with
10.00 P.s.i. operation pressure and 24 P.s.i Max.
inflate .
Brake system
front and rear disc brake
Rated loading capacity
65KG
Max. speed (1000W36V)
26KM/hour
Max. speed (1300W48V)
29KM/hour
Range per charge(36V12A)
19KM
Range per charge(48V10A)
19KM
Range per charge(48V13A)
24KM
Wheelbase(mm)
780
Dry Weight (KGS)
42KG / 49KG
Dimension (mm)
1165×725×765
Min ground clearance (mm)
70
Seat height (mm)
550
Carton size (mm)
1030*640*530
