ELECTRIC MINI ATV
OWNER’S MANUAL
Read and understand this entire manual before using!
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
OFF ROAD USE ONLY!!!
NEVER OPERATE THIS VEHICLE IF YOU ARE UNDER
AGE 12!!!

Table of Contents

Questions and Answers

  • L
    Lauren HopkinsAug 4, 2025
    How to fix an ATV ELECTRIC MINI that does not run?
    • J
      Jessica RodriguezAug 4, 2025
      If your ATV Offroad Vehicle doesn't run, the battery might be undercharged. Charge the battery; a new one should be charged for at least 12 hours before the first use and up to 8 hours after each subsequent use. Also, check all connectors to ensure they are tightly plugged in, including the charger connector and the wall outlet. Confirm that there is power flowing to the wall outlet. If the charger isn't working, test it with a volt meter or have an authorized service center test it for you.
  • W
    William PriceAug 8, 2025
    Why does my ATV Offroad Vehicle have a short run time?
    • K
      Katrina WilsonAug 9, 2025
      If your ATV Offroad Vehicle has a short run time (less than 15 minutes per charge), the battery might be undercharged. Charge the battery; a new one should be charged for at least 12 hours before the first use and up to 8 hours after each subsequent use. Check all wires and connectors to ensure they are tightly plugged in, including the battery connector, charger connector, and the wall outlet. Make sure power is flowing to the wall outlet. The battery could also be old and not accepting a full charge; the average battery life is 1 to 2 years, so consider replacing it. Also, make sure that the brakes are adjusted properly.
  • S
    Sarah SmithAug 13, 2025
    What to do if ATV ELECTRIC MINI Offroad Vehicle was running but suddenly stopped?
    • M
      Manuel HarringtonAug 13, 2025
      If your ATV Offroad Vehicle was running but suddenly stopped, check all wires and connectors to ensure they are tight. A burned-out fuse could also be the cause, which automatically shuts off the power if the motor is overloaded. An excessive overload could cause the motor to overheat. Refer to replacing the fuse instructions of this manual. Correct the conditions that caused the fuse to burn out and avoid repeatedly burning out fuse. If you suspect motor or electrical switch damage, contact the authorized service center for diagnosis and repair.
  • M
    Marvin JohnsonAug 19, 2025
    Why is my ATV ELECTRIC MINI Offroad Vehicle running sluggishly?
    • B
      Brenda DownsAug 19, 2025
      If your ATV Offroad Vehicle runs sluggishly, it might be due to stressful driving conditions. Use it only on solid, flat, clean, and dry surfaces like pavement or level ground. Ensure the tires are properly inflated, referring to the tire instructions. Avoid overloading the vehicle by exceeding the maximum weight limit, allowing more than one rider, going up steep hills, or towing objects. Overheating can also cause sluggishness; if this happens, correct the driving conditions, wait 5-10 minutes, and resume riding, avoiding repeated overheating.
  • M
    Michael HamiltonAug 23, 2025
    Why does my ATV Offroad Vehicle sometimes not run?
    • A
      Ashley RobertsonAug 23, 2025
      If your ATV Offroad Vehicle sometimes doesn’t run, check all wires around the motors and connectors to ensure they are tight. If the issue persists, there may be motor or electrical switch damage, in which case you should contact the authorized service center for diagnosis and repair.
  • P
    pachecojohnAug 28, 2025
    What to do if ATV ELECTRIC MINI does not stop when applying the brake?
    • M
      Michael MillerAug 28, 2025
      If your ATV Offroad Vehicle does not stop when applying the brake, the brakes may not be adjusted properly. Refer to brake instructions to properly adjust Brakes.

Summary

SAFETY WARNINGS

Rider Age and Supervision

Specifies age limits (12+) and adult supervision requirements (under 16).

Rider Training and Experience

Stresses the importance of technical training and rider maturity.

RIDING PRACTICES AND ATTIRE

Riding Environment and Safety

Covers off-road use, avoiding public areas, and defensive riding.

Riding Limitations and Risks

Warns against aggressive riding, exceeding limits, and unsafe conditions.

Essential Protective Gear

Mandates helmets, elbow pads, kneepads, and appropriate footwear.

USING THE CHARGER

Charger Safety and Maintenance

Details charger inspection, safe charging practices, and precautions.

WARNING STICKER LOCATION

Sticker Identification and Purpose

Identifies warning sticker locations and their importance.

WARNING STICKER A DETAILS

Key Safety Directives

Covers helmet use, no public roads, no passengers, no drugs/alcohol.

WARNING STICKER B DETAILS

Age and Supervision Reminder

Reinforces minimum age of 12 and adult supervision for under 16.

WARNING STICKER DETAILS

Tire Pressure and Moving Parts Hazards

Alerts to control loss from tire issues and hazards from moving parts.

Motor Burn Hazard Warning

Warns that the electric motor gets hot and to avoid touching it.

LOCATION OF PIN

Product Identification Number

Explains the location and significance of the PIN.

BEFORE YOU BEGIN ASSEMBLY

Unpacking and Inspection Guide

Instructions for unpacking and checking for shipping damage.

VEHICLE ASSEMBLY

Rear Wheel and Front Shock Installation

Instructions for mounting the rear wheel and front shock absorber.

Front Wheel Assembly

Steps for assembling and mounting the front wheel.

ASSEMBLY COMPONENTS

Tie Rod and Bumper Installation

Instructions for connecting the tie rod and mounting the bumper.

Front Brake Caliper Installation

Procedure for installing the front brake caliper.

HANDLEBAR ASSEMBLY

Securing the Handlebars

Instructions for assembling and tightening the handlebars.

TIRE INFLATION

Tire Inflation Procedure

Guides on inflating tires to the correct pressure.

TIRE CARE AND CONTROLS

Tire Pressure, Maintenance, and Aging

Covers tire pressure, maintenance, replacement, and aging.

Handle Drive Controls Identification

Identifies and describes handlebar controls.

3-FUNCTION ADJUSTABLE SWITCH

Switch Settings and Functions

Explains adjustments for throttle, speed, and motor power.

SLEEP MODE FEATURE

Automatic Sleep Mode

Describes the battery-saving sleep mode feature.

REMOTE CONTROL OPERATION

Using the Remote Control

Instructions for starting/stopping the motor and effective range.

TECHNICAL SPECIFICATIONS

Vehicle Performance Data

Details motor, battery, speed, range, weight, and dimensions.

PRODUCT MAIN PART DIAGRAM

Component Identification

Labels major parts of the ATV in diagrams.

BEFORE RIDING CHECKS

Battery Charging Procedure

Instructions for initial and ongoing battery charging.

Essential Pre-Operation Checks

Lists critical items to inspect before riding.

REPAIR AND MAINTENANCE

Pre-Ride Inspection Checklist

Covers checks for loose parts, brakes, frame, tires, and safety gear.

Brake Adjustment Procedure

Provides instructions for adjusting the front and rear brakes.

CHAIN ADJUSTMENT

Adjusting Chain Tension

Details on adjusting chain slack to approximately 4mm.

FUSE REPLACEMENT

Fuse Replacement Safety Guide

Explains safe fuse replacement, emphasizing ignition status.

TROUBLESHOOTING GUIDE

Vehicle Not Running or Stopping

Solutions for issues like the vehicle not running or stopping suddenly.

Short Run Time Issues

Addresses causes for reduced battery life and run time.

CIRCUIT DIAGRAM

Electrical System Layout

Illustrates the wiring diagram for the ATV's electrical components.
