TH115 (modelos 120S/240S/240D)
7
ESPAÑOL
NOTA: conectar los cables utilizando conectores sin soldadura para cables de cobre.
Diagramas de conexiones
Blanco (120S)
Rojo (240D)
alimentación
carga
negro
rojo
alimentación
carga
negro
Modelos 120S / 240D
Modelo 240S
69-2617EFS-01 (5 x 3.125).book Page 7 Thursday, November 21, 2013 1:47 PM
