TH115 (120S/240S/240D models)
7
ENGLISH
NOTE: Connect the wires using the provided solderless connectors for copper wires.
Wiring diagram
Power
Load
Power
Load
120S / 240D models
240S model
Black
Black
Red
White (120S)
Red (240D)
69-2617EFS-01 (5 x 3.125).book Page 7 Thursday, November 21, 2013 1:47 PM
