AUDAC CELO5 User Manual

8
Additional Information
Technical specifications
RMS Power 50 Watt
Max. Power 100 Watt
Nominal impedance 8 Ohm
Sensitivity 1W / 1m 85 dB
Sound pressure Max W / 1m 102 dB
Frequency response -3 dB 70 Hz - 20 kHz
Cross-over frequency 3.0 kHz
Cross-over network Passive Built-in
Drivers 1” HF Alu tweeter
5” MF / LF Alu woofer
Connectors Gold plated spring clamps
Mounting 4-Screw Quick-Fixing Mechanism
Construction High-Quality ABS
Front finish White Thin edge grill (RAL9003)
(1 mm width x 3.2 mm height edge)
Dimensions Ø 175 x 98 mm
Cut-out measurement Ø 155 mm
Built-in depth 95 mm
Weight 1 Kg
Packaging Carton box
Shipping weight & Volume 1.5 Kg - 0,0069 Cbm
Accessories included Cut-out template
Instruction manual

AUDAC CELO5 Specifications

Power

RMS power	50 Watt
Max power	100 Watt
Nominal impedance	8 Ohm

Acoustic Specifications

Sensitivity	85 dB
Sound pressure max	102 dB
Frequency response	70 Hz - 20 kHz
Cross-over frequency	3.0 kHz

Drivers

HF driver	1” HF Alu tweeter
MF / LF driver	5” MF / LF Alu woofer

Weight and Dimensions

Dimensions	Ø 175 x 98 mm
Cut-out measurement	Ø 155 mm
Built-in depth	95 mm
Weight	1 Kg
Shipping weight	1.5 Kg
