Chapter 4
Additional information
Technical specifications
Control Front panel
RS-232
Inputs F-type antenna connection (75 Ω)
FM Tuning Range (-10 dB) 87.5 ~ 108 MHz
Sensitivity (1W/1m) -108 dBm
Signal / Noise 52 dB
THD+N (@ 1 kHz) 0.22%
Frequency Response (± 3 dB) 30 Hz - 12.5 kHz
Crosstalk (@ 1 kHz) 26 dB
DAB Tuning Range (-10 dB) Band-3 171 ~ 240 MHz
L-Band 1452 ~ 1492 MHz
Sensitivity (1W/1m) -99 dBm
Signal / Noise 81 dB
THD+N (@ 1 kHz) 0.026%
Frequency Response (± 3 dB) 42 Hz - 20 kHz
Crosstalk (@ 1 kHz) 53 dB
Outputs Type Balanced stereo line outputs (3-pin Euro
Terminal Block (Pitch-3.81 mm)
Level +8 dB ~ -32 dB
Power Consumption 0.7 W
Dimensions (W x H x D) 482 x 44 x 330 mm
Weight 3.150 kg
Mounting 19”
Unit height 1 HE
Construction Steel
Colours Black
