Additional Information
Technical specifications
RMS Power 60 Watt
Max. Power 120 Watt
Nominal impedance 8 Ohm
Sensitivity 1W / 1m 88 dB
Sound pressure Max W / 1m 106 dB
Frequency response -3 dB 55 Hz - 20 kHz
Cross-over frequency 3.0 kHz
Cross-over network Passive Built-in
Drivers 1” HF Alu tweeter
6” MF / LF Alu woofer
Connectors Gold plated spring clamps
Mounting 4-Screw Quick-Fixing Mechanism
Construction High-Quality ABS
Front finish White Thin edge grill (RAL9003)
(1 mm width x 3.2 mm height edge)
Dimensions 196,5 x 276,7 x 82 mm
Cut-out measurement 174 x 254 mm
Built-in depth 78,5 mm
Weight 1.66 Kg
Packaging Carton box
Shipping weight & Volume 2.1 Kg - 0,0083 Cbm
Accessories included Cut-out template
Instruction manual
