Installation Procedure
1) Cut a hole in the ceiling or wall on the desired mounting location of the loudspeaker. This should be a
square with the following dimensions: 147mm x 147mm. The included cutout template can be used
for marking.
2) Provide the loudspeaker connection cable through the mounting hole.
3) Take the loudspeaker, and remove the front grill.
The front grill can be removed by rotating the mounting clips outwards and pushing them down. The
fixing screws will push the front grill out.
4) Pull the mounting clips up again, and rotate them inwards, making the speaker fit through the
mounting hole in the ceiling.
