Audi 2008 A4 - 3 Sequence of Operations; Preparations

3 Sequence of operations
3.1 Preparations
– Disconnect the battery -A- ⇒
.
– Remove the right and left luggage compartment trim ⇒ Rep.
gr. 70.
– Remove the sill panel(s) from the right side of the vehicle ⇒
Rep. gr. 70.
– Remove the glove compartment ⇒ Rep. gr. 68.
– If installed, remove the control unit for the digital sound
package -J525- incl. holder ⇒ Rep. gr. 91.
Right-hand drive vehicles
– Remove the rear seat bench ⇒ Rep. gr
. 72.
– Remove the centre console ⇒ Rep. gr. 68.
– Remove the dash panel cover on the driver side ⇒ Rep. gr.
68.
