Location
Choose a location that can support the weight of your device. Its operating principle of dissipating
heat allow a space of 10 cm around the player so that its ventilation could happen naturally. Move it
away from sources of heat or vibration ; do not expose it directly to sunlight. Do not locate the unit
close to electroluminescent light sources since they can cause troubles with the remote control
working. For your convenience when loading a disc and playing the display, place your player at a
sufficient height from the floor or at viewing height.
Make sure it is close to the preamplifier or the integrated amplifier so that the lenght of the cables
connecting that is short as possible. In the case the integrated amplifier or preamplifier is not close
with the FLCD3S, it is preferable to use balanced interconnection cables between them to avoid any
noise.
Communication betweeen Audia and other brands
On the rear of the FLCD3S, you will find an outlet «Trigger» format 3.5 mm jack.
This connection allows devices from differents manufacturers that have adopted this mode of
communication and equipped with the necessary taken to control its implementation on or standby
simultaneously.
Output connections
On the rear of the player, you have two outputs (OUTPUT) : one symmetrical format, XLR, and a
format of an asymmetric pair of RCA jacks.
Using a pair of cables terminated with XLR connectors for balanced transmission or by praying for
RCA unbalanced use, connect the left and right channel outputs of FLCD3S respectively to left and
right channels of the input of a stereo amplifier. Several outputs can be used simultaneously.
The use of interconnect cables of the highest quality is strongly recommended. The polarity of the
pin XLR connectors output is shown on the diagram below:
Your player is also equipped with a S/PDIF coaxial digital output on an RCA socket allowing the
use of an external converter with a suitable cable (75 Ω) not supplied. The available signal is in
16bit/44.1kHz.
