Page -6-© Audient Ltd
Installation
Ventilation
Care should be taken not to obstruct the series of ventilation
holes in the metalwork of the console. The desk is designed to
release heat and take adequate air flow via these holes to
ensure longevity of performance.
These can be found along the left hand bottom edge on the side
panel (below the cheek), the rear top wrap-around ventilation
panel and below the faders at the foot of the console.
If mounting the console into some form of studio furniture or
desk, please ensure that there are sufficient air gaps at these
locations.
The console can also be rack mounted
with the rack ear kit and will occupy
13RU plus connector space (suggest
15RU total) - please ensure that these
ventilation holes are not restricted.
Perhaps consider using a vented 19”
blanking plate to cover the connector
space, providing adequate air flow
to the top ventilation plate.
