Audient EVO 4 Quick Guide

04
Smartgain Mode
The Smartgain LED will start ashing
red and the volume wheel LED’s will
illuminate indicating that Smartgain
Mode is now listening
Smartgain Mode will dial in the
correct levels and when complete
the Smartgain button will ash green
twice to indicate it has been successful
Start playing or performing into the
microphone
5
6
7
You are now ready to start recording
8
Press the Smartgain button to begin
The Smartgain LED will illuminate green
and the input channel LEDs (1 & 2) will
begin to ash (indicating a channel
must be selected)
Press one or more of the input channel
buttons to select the channels to be
adjusted
Press the Smartgain button again to
begin the process
1
2
3
4

Audient EVO 4 Specifications

General

Type	Audio Interface
Number of Preamps	2
Bit Depth	24-bit
Bus Powered	Yes
Direct Monitoring	Yes
Loopback	Yes
Phantom Power	48V
Sample Rate	96 kHz
Inputs	2 x XLR/TRS Combo
Outputs	2 x TRS
Simultaneous I/O	4 in / 4 out
USB	USB-C
Driver	Class Compliant
