Audient iD14 User Manual

1211
Microphone Preamplifiers
& Line Inputs
iD14 features two classic Audient
microphone preamplifiers. These preamps
are based on designs from Audient’s classic
consoles and are the same that are used
across our entire product range.
The design features discrete Class-A
circuitry providing exceedingly low distortion
and noise performance. From a sonic point
of view, iD14 is fast, open and detailed.
Neutrik
TM
XLR/TRS Jack combi-connectors
provide microphone and line inputs. The line
inputs are padded through the microphone
preamplfiiers.
NOTE
Due to power restrictions over USB and the
requirements of the high quality mic pres and
converters, phantom power is only enabled
when using the 12V power supply.
The microphone preamplifiers feature:
• 56 dB of clean gain
• 48v (±4V) phantom power rated at
10mA/channel
• > 2.8kΩ input impedance which provides
a punchy tone from any microphone
transducer type
• Extra features such as a +10dB boost
and polarity reverse can be
accessed via the iD App (See page 19).
HARDWARE FEATURESHARDWARE FEATURES
HARDWARE

Audient iD14 Specifications

General

Type	USB Audio Interface
Input Channels	2
Output Channels	4
Preamps	2
Phantom Power	Yes
A/D Resolution	24-bit
Bit Depth	24-bit
Headphone Output	1 x 1/4"
MIDI I/O	No
Digital Inputs	1 x Optical Toslink (ADAT)
USB	1 x USB Type B
OS Compatibility	Windows, macOS
Sample Rate	44.1kHz, 48kHz, 88.2kHz, 96kHz
Analog Inputs	2 x XLR/TRS Combo (Mic/Line)
