21
Frequency Response: +0-3dB, 0.4Hz to 200kHz at rated output (Balanced, 200k ohms load).
THD + noise: Less than .007% at 2V RMS BAL output.
Dynamic Range: >122 dB (AES17)
Gain: Main output: 18.5dB Balanced output, 12.5dB SE output. Record out: 0dB (Processor input: 0dB BAL
output).
Input Impedance: 100K ohms Balanced, 50K ohms SE. Inputs: 4 balanced, 4 single-ended. Assignable
processor passthrough.
Output Impedance: 600 ohms Balanced, 300 ohms SE Main (2). 20K ohms minimum load and 2000pF
maximum capacitance. Outputs (3): 2 main, 1 record out (XLR and RCA connectors).
Output Polarity: Non-inverting.
Maximum Input: 16V RMS BAL, 8V RMS SE.
Rated Outputs: 2V RMS (1V RMS SE) into 200K ohm balanced load (maximum balanced output capability
is 17V RMS at less than 0.5% THD at 1kHz).
Crosstalk: -105dB or better at 1kHz.
Controls: Rotary encoders: Volume (103 steps), Select Input. Push Buttons: Power, Menu, Enter, Mono,
Invert, Mute.
Power Supplies: Electronically regulated low and high voltage supplies. Automatic 45 sec. warm-up/
brown-out mute. Line regulation better than .01%.
Noise: Less than -100 dBv at maximum volume (103).
Tube Complement: (4)-6H30P dual triodes.
Power Requirements: 100-125VAC 60Hz (200-250VAC 50/60Hz) 130 watts. Standby: 2 watts.
Dimensions:
Width 19” (48 cm)
Height 6.5” (13.7 cm)
Depth 13.7” (34.8 cm)
Handles extend 1.6” (4 cm) forward of the front panel.
Weight: 15.9 lbs. (7.2 kg) Net; 24 lbs. (10.9 kg) Shipping.
Specications
