Audio Technica AT2020USB+ Instruction Manual

4
1. Capsule — Condenser microphone element with cardioid polar pattern
2. Blue LED — Blue light shows microphone is receiving USB power
3. Headphone Level Control — Dial controls headphone volume
4. Mix Control — Blends microphone and pre-recorded audio
5. Headphone Jack —
1
/
8
-inch (3.5 mm) stereo jack for connecting your headphones
6. Metal Construction — Tough, durable, resilient design
7. USB Connector — Use the included USB cable to connect AT2020USB
+
to your Mac or PC
8. USB Cable
Setting up your microphone with included pivot mount and tripod desk stand
A. Screw the pivot mount onto the top of the tripod desk stand.
B. Place the tripod desk stand on a flat surface. (The tripod legs will extend to provide a wide,
secure base.)
C. Install the AT2020USB
+
microphone into the threaded collar of the pivot mount and tighten
collar while holding the microphone in place. The front of the microphone should be facing the
sound source. (A USB icon and blue LED indicate the front of the microphone; the product model
number is displayed on the rear of the microphone.)
D. If necessary, adjust the microphone’s angle with the pivot mount’s thumbscrew.
E. Plug the provided USB cable into the USB digital output at the base of the microphone.
Note: Many recording software programs are available online. Audacity is widely used free software
for recording and editing sounds. It is available online at http://audacity.sourceforge.net/
AT2020USB
+
1
6
3
4
7
5
(on back)
2
8

Audio Technica AT2020USB+ Specifications

General

Type	Studio microphone
Bit rate	16 bit
Sample rate	48 kHz
Microphone frequency	20 - 20000 Hz
Microphone direction type	Cardioid
USB port	Yes
Connectivity technology	Wired
Cable length	3.1 m
Product color	Black
Number of products included	1 pc(s)
Battery operated	No

Weight and Dimensions

Microphone weight	374 g
