Page #7 background imageLoading...
Page #7 background image
7
Features of ATUC‑IRDU
One IRDU unit is shared by two people to support 2-person
conversation mode. Equipped with two headphone outputs with
independent volume adjustments
Equipped with two multifunction buttons that can be flexibly
changed as appropriate to user’s applications
Features of ATUC‑IRA
White IR cover and slender style provide subtle design that can be
installed in a variety of locations
Using BNC terminal makes it possible to do multiplex
transmissions by connecting one cable
Reliable design prevents installation mistakes with LEDs that
indicate power supply status
Features of ATUC‑50IU
Discussion units that can be embedded in the ATUC-50 system
Configure the system simply by connecting the microphones,
speakers, headphones, etc.
GPIO control terminal built in for monitoring conditions and
controlling external devices
Equipped with 2 RJ-45 terminals for connecting discussion units
(ATUC-50DU), etc.
Designed for the high sound qualities of 24 bit/48 kHz
Integration unit (ATUC-50IU) can be set from the Web Remote
for the chairperson/delegate names
Conference Mode and volume can be set for each integration unit
(ATUC-50IU)
Features of ATLK‑EXT165
Connects to any Audio-Technica device, such as a control unit
(ATUC-50CU), or discussion unit (ATUC-50DU), and is
equipped with two RJ-45 terminals that can expand the discussion
system
Remote mode that automatically starts from the control unit
(ATUC-50CU)
Has a standalone mode that can be started by operating the front
panel
Equipped with GPO terminal that notifies external devices when
an overcurrent (2.6 A) is detected in the power supplied from
RJ-45 terminals
Features of ATUC‑VU
The voting unit is compatible with the ATUC-50DUa and can be
used with the ATUC-50 and ATUC-IR systems
Power can be supplied by the ATUC-50DUa extension terminal
(RJ-11 Modular Terminal)
All buttons and all LEDs can be flexibly controlled and functions
can be assigned from the IP Control
Equipped with NFC card reader function, ID numbers can be
transmitted through the IP Control
Can be used as expansion panel when connected to ATUC-50DUa
for which Priority settings are turned on (chairman and other
functions can be assigned)
Maximum 300 Voting Units can be used (when 3 CU Links are
connected) on the ATUC-IRCU system; maximum 300 Voting
Units can be used (when 3 CU Links are connected) on the
ATUC-50CU system
Features of ATUC‑M43H/58H/32L
Equipped with an LED ring that enables power supply via 3-pin
balanced connector while offering both high sound quality and
user flexibility
Structural design reduces vibration between microphone
connectors and discussion units
Adopted double layer pop filter
Improves RF measures against external radio waves
Double gooseneck design makes installation flexible (ATUC-
M43H and ATUC-M58H)
Super directional design allows capture of distant sounds (ATUC-
M32L)
Optional products (sold separately by
Audio‑Technica)
Model
number
Name Use
ATUC-DUWT DISCUSSION UNIT
WEIGHT PLATE
Use this to improve the
stability of discussion unit
installation.
AT8643 RACK MOUNT KIT Use this when rack mounting
half-rack sized products, such
as link extenders (ATLK-
EXT165).
