Owner’s Enjoyment Manual
®
KEY FEATURES OF YOUR MVC
• Master volume control for your system (one knob does it all)
• Trunk Mounted Chassis (easy to install)
• Six channels of input and output (lots of control)
• Connectable inputs (2 channels in can give you 6 out)
• Linkable control for multiple MVCs
• (more outputs ouh ouh ouh)
• High signal voltage capabilities
• (drive a lot in, control it with one knob)
• Output level controls (balance the voltage to your amps)
• Signal voltage indicator LEDs (level-matching made easy)
• Adjustable delay amplifier trigger output (no more pop)
• High headroom PWM switching power supply
• (compensates for vehicle voltage fluctuations)
QUICK INSTALLATION INFO
For those of you who have many sophisticated installations
under your belt, please refer to the diagrams on pages 13 through
16 for guidance in installing your MVC. If you are curious, your
MVC is shipped with the following configurations:
Feature Factory Setting
Inputs Independent
PFM Module 33 Hz
Remote Out turn-on delay 1.5 seconds
Power Ground Isolation Isolated
Note: These configurations can be changed via the internal
jumpers.
A word of advice and warning must come from us at this
time. It is highly recommended that you retain the services
of your authorized AudioControl dealer to install your MVC.
Not only do they have training, tools, and know-how to do
the job right the first time, we extend your warranty from
one year to FIVE FULL YEARS.
Should you still decide to install your
MVC yourself, we encourage you to
read this manual thoroughly
and reference it during the
actual installation. Good luck!
2
