b. In Line Connection For these applications,
the Live AN Split provides XLR connectors and
1/4" TRS phone jack to easily interface with
most professional audio devices. Follow the
conguration examples below for your par-
ticular connection.
• Balanced
• Unbalanced
Rack Mounting
The most secure mounting is on a universal rack
shelf available from various rack manufactures
or your music dealer. The Live AN Split ts into
one standard 19" rack unit of space. Please allow
at least an additional 4" depth for the connectors
on the rear panel. Be sure that there is enough
air space around the unit for sucient ventilation
and please do not place the Live AN Split on high
temperature devices such as power ampliers etc.
to avoid over heating.
