P. 2
AUDIOLAB Live AN Split -
LIVE AN SPLIT
Professional splitter & mixer - 2 inputs & 6 outputs
Live AN Split is a professional audio solution that
can be used as a splitter or as a mixer. With two
inputs and six outputs, balance and level controls
per channel, and occupying a single rack unit, the
xture is a versatile tool that allows the user to
multiply the signal without losing quality. Live AN
Split also has LED indicators per channel, 4 XLR &
2 1/4" TRS connectors that can be easily switched
between mixer and splitter mode.
Specications
Features
• 1 rack unit
• Splitter / Mixer switch for each mono channel
• 6+2 outputs / splitter mode
• Level/Pan control per channel
• Main input and output level control
• 4 XLR / 2 TRS 1/4" balanced connectors
Audio Inputs
• Connectors: XLR and 1/4" TRS
• Type: RF ltered, servo-balanced input
• Impedance: 50 kOhms balanced, 25 kOhms
unbalanced
• Nominal operating level: -10 dBV to +4 dBu
• Max. input level: +21 dBu balanced and unbal-
anced
• CMRR Typ.: 40 dB, > 55 dB @ 1 kHz
Audio Outputs
• Connectors: XLR and 1/4" TRS
Type: Electronically servo-balanced output
stage
• Impedance: 60 Ohms balanced, 30 Ohms
unbalanced
• Max. output level: +22 dBu balanced and
unbalanced
System specications
• Frequency response: 5 Hz to 200 kHz, +/- 3 dBu
• S/N ratio: >95 dBu, unweighted, 22 Hz to 22 kHz
• THD: <0.002 % typ. @ +4 dBu, 1kHz, gain 1
Control
• Main input level: variable
• Main output level: variable
• Level: variable for each channel
• Balance/pan: placing in the stereo eld
• Main Link: links the main input signal to the
main output
• Split/mix: changeover from split to mix mode
for each channel
Indicators
• Input level (main): 6-digit LED display: -18/-
12/-6/0/+12/Clip
• Output level (main): 6-digit LED display: -18/-
12/-6/0/+12/Clip
• Input/output level: 6-digit LED display: -18/-
12/-6/0/+12/Clip
Physical
• Dimensions: 483x195x44 mm. / 19x7.54x1.7 in.
• Weight: 2.6 Kg. / 5.73 Lbs.
1. OVERVIEW
English version
