VEHICLE INSTALLATION
To install the units to the back seat of a car:
1. Clamp front bracket (A) and rear bracket (B) around the headrest posts.
2. Secure the brackets in place with four Phillips head screws (C).
3. Slide the quick disconnect bracket (D) into the rear bracket (B).
4. Install the unit on to the three hooks on the mounting plate (E).
5. Rotate the unit to the desired viewing position.
To remove the unit:
1. Press the buttons on both sides of the quick disconnect bracket (D).
2. At the same time, pull the quick disconnect bracket (D) out of the rear bracket (B).
7
A
B
C
D
E
