Audiovox DV 1680 User Manual

Attention! The DVD Player's A/V cable contains three
wires:
- White for audio left channel
- Red for audio right channel
- Yellow for video signal
If not connected correctly, there will be no response
from the external equipment.
Most audiovisual equipment has an IN/OUT switch.
Make sure that the switch on other components is set to
IN when receiving incoming signals.
8.2 S-VHS Out
Some equipment is equipped with a S-VHS terminal,
which you can use instead of the RCA video terminal.
The picture quality of a S-VHS signal is better than an
ordinary RCA signal.
When you use the S-VHS cable, you do not need to
connect the Yellow RCA video cable.
The RCA terminal will send out a signal at the same
time, and you may connect it to another TV set.
37

Audiovox DV 1680 Specifications

Power

power adapter voltage	12 V
power adapter current	2 A
playing time with battery	3.5 hours

Display

display size	6.8 inches
display type	TFT-LCD
display resolution	384 x 234

Weight and Dimensions

weight without battery pack	1 kg
width	168.3 mm
depth	172 mm
height	35 mm
