-5-
1. Power Button: Press and hold this button for 2 seconds to turn the
transceiver on or off.
2. Push-to-Talk Button (PTT): Press to transmit. Release to receive.
3. Monitor Button: Press and hold to bypass the squelch and listen to chan-
nel activity; a momentary press activates LCD backlighting for 5 seconds.
4. Clip
5. Battery Compartment: Accepts 4 “AAA” batteries.
6. Speaker
7. Microphone (MIC)
8. SCAN Button: Press this button to initiate an automatic scan of FRS
channels 1-14.
9. Down Button: Press this button to decrease the volume or channel set-
ting as well as adjustment of other functions.
10. Up Button: Press this button to increase the volume or channel setting.
11. LCD Display: Displays the current FRS channel number as well as other
functions as well as adjustment of other functions.
12. Function Select Button: Press this button to select and toggle through
all unit functions.
13. VOX Button: Press this button to activate the Voice-Operated Trans-
mission function.
14. Fixed Antenna
15. Microphone/Charger (MIC/CHG) Jack: For use with an optional external
headset/microphone or supplied wall adapter battery charger input.
16. Speaker (SP.) Jack: For use with an optional Audiovox approved
optional speaker accessory.
17. Charging Contacts: Used to recharge batteries when unit is placed in
Desk-Top Charger.
