7
ELECTRICAL CONNECTIONS
(OPTIONAL)
DIGITAL AUDIO
DVD PLAYER
AC/DC
ADAPTER
CIGARETTE LIGHTER ADAPTER
REMOTE CONTROL RECEIVER
(OPTIONAL)
DC 12V IN DC 12V OUT
REMOTE
DIGITAL
AUDIO
A/V OUT
L/R VIDEO
VIDEO OUT
AUDIO R OUT
AUDIO L OUT
WHITE
RED
YELLOW

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Audiovox MMDV2 and is the answer not in the manual?

Audiovox MMDV2 Specifications

Power IconPower
supply voltage12V DC
test voltage14.4V
current consumptionLess than 2A
Audio Output IconAudio Output
audio output level600Ω (2 ch 2.0 Vrms)
frequency response20 Hz - 20 KHz
S/N ratio90 dB (JIS)
