Audiovox PRO9276C User Manual

128-8784b
3 of 28
3
12 Pin Main Wiring Harness #1123751
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
Yellow/Black (+) Output To Control Factory Alarm
Green/Orange Tachometer Input
Black Chassis Ground
Gray/Black Negative Inhibit Shutdown Input (-)
Light Blue Ground Output While Running (-) 300mA
Green/Yellow Diesel Wait To Start Input
Gray Shutdown Input (-)
No Connection
Brown Positive Inhibit Shutdown Input (+)
Brown/Black Brake Shutdown Input (+)
White Parking Light Output
White Parking Light Input
5 Pin Aux Channel Output Harness #1123762
Light Blue/Green Channel 5 Output (-) 300mA
5 Pin Antenna Harness Part # 1123905
Dark Blue Channel 3 Output (-) 300mA
Green/Black Channel 4 Output (-) 300mA
4
5
Light Blue/Black Channel 6 Output (-) 300mA
Blue/Red Channel 7 Output (-) 300mA
3 Pin Accessory Output Harness #1123310
1
2
3
Green/White Dome Illumination Output (-) 300mA
Blue/Black External Activation Triogger Input
Black/White Horn Output (-) 300mA
