Audiovox PRO9276C User Manual

128-8784b
4 of 28
4
6 Pin Power / Start Harness #1123742
1
2
3
4
5
6
Purple Accessory (+)
Blue Ignition 1 (+)
Red Battery 2 - 12V (+)
Red/White Battery 1 - 12V (+)
Yellow Starter Output
Green Ignition 2 (+)
4 Pin 3rd Ignition / Start Harness #1123743
1
2
3
4
Orange/Black Parking Brake Input (-)
N/C N/C
Red/Black Ignition 3 Input
Pink Ignition 3 Output
4 Pin Alternate Output Harness #1122585
1
2
3
4
Black/Blue Factory Disarm / Pulse Beffore Start (-)
Black/Green Factory Arm / Pulse After Start (-)
Black/Red Pulse After Shutdown (-)
Black/Yellow Pulse During Crank (-)
3 Pin Door Lock Output Harness #1122906
1
2
3
Red (-) Lock / (+) Unlock
Green (+) Lock / (-) Unlock
Red/Black (-) 2nd Unlock
2 Pin Transponder Output Harness #1123292
1
2
Red Battery (+) 100mA
Black (-) Output While Running 100mA
