USING THE TFT MONITOR
Open/Close TFT Monitor
Open TFT Monitor
Press the OPEN button (1) on the front panel or press the ( ) button (25) on the remote control to activate the mecha
nism that moves the display panel into the viewing position.
Close TFT Monitor
Press the OPEN button (1) on the front panel or press the ( ) button (25) on the remote control to load the display
panel back into the compartment.
TFT Monitor Auto Open
If “TFT Auto Open” is “on” when the unit is turned on, the monitor automatically moves to the viewing position. If “TFT
Auto Open” is ”off” when the unit is turned on, press the OPEN button (1) or ( ) button (25) on the remote control to
move the monitor into the viewing position. If “TFT Auto Open” is set to ”Manual”, the TFT will not close when the key
is turned off.
Monitor Tilt Angle Adjustment
A known characteristic of LCD panels is the quality of the display in relationship to the viewing angle. The monitor angle
can be adjusted for optimum viewing using one of the following methods.
Step by Step Angle Adjustment
Press the or button on the control panel (23, 24) or remote control (26, 27) to adjust the tilt angle of the screen one
step at a time.
Continuous Angle Adjustment
Press and hold the or button on the control panel or remote control to adjust the tilt angle in a continuous motion.
Reverse Driving Use
If the rear-view video camera is connected, the unit is on, and the monitor is stationed inside the main compartment of
the unit, the monitor automatically moves into the viewing position and switches to CAMERA mode upon reverse dri-
ing. When the reverse driving stops, the monitor returns to the main storage compartment. If the monitor is in display
mode, the monitor automatically switches to CAMERA mode upon reverse driving. When the reverse driving stops, the
monitor returns to its original input mode.
67
Subject to technical changes
