Audiovox VXE 7020 NAV Installation Guide

7
BT Antenna (Do not cut off !)
Yellow / CAMERA
Black / MICROPHONE
DAB BUS
Camera
TMC
Steering Wheel Control (SWC) requires
Dietz Interface Adapter (sold separately)
Rear Right
Rear Left
Front Left Front Right
White / Front L (+)
Grey with black stripe / Front R (-)
White with black stripe / Front L (-)
Grey / Front R (+)
Purple / Rear R (+)
Purple with black stripe / Rear R (-)
Green / Rear L (+)
Green with black stripe / Rear L (-)
BRAKE
PINK
SWC
BLACK
GPS ANT
REVERSE
Antenna
YELLOW
RED
ORANGE
BLUE
GND
BATT+
ACC
Illumination
ANT.CONT
GREEN/WHITE
CAMERA
POWER AMPLIFIER
AV-SYSTEM
BLACK
Yellow
Red
Red
White
Red
Blue
White
White
SUB OUT
Yellow
Video Out
AV-IN
REAR FRONT
TMC module
Blue / ANT.CONT
Red / ACC Black / GROUND Yellow / BATTERY 12V+ Orange / Illumi
nation
Orange / Illumination
Yellow / Battery 12V(+)
Black / Ground
Red / ACC
Blue / ANT.CONT
ANSCHLUSSDIAGRAMM / WIRING DIAGRAM
IMPORTANT: Incorrect wiring connections can damage the unit. Follow the wiring instructions carefully, or have the installation
handled by an experienced technician.
