VR 404 BLOCK DIAGRAM
L mH C µFL mHC
µF
60
80
100
120
150
200
10.6
7.9
6.4
5.3
4.3
3.2
660
495
400
330
265
200
21.0
15.9
12.7
10.6
8.5
6.4
330
245
200
165
132
100
4 Ohms
8 Ohms
LOUDSPEAKERS IMPEDANCE
FREQUENCY
Hertz
VR 404 XR
FRONT SYSTEM (HI-PASS) AND SUBWOOFER (LO-PASS)
WITH OR WITHOUT FADER
