Parts description: (pages 6, 7, 10 to 13)
Winter period
• In case of approaching frost with risk of freezing of the pressure filter,
disconnect it and protect it from frost.
• Empty the pressure filter in autumn and store it frost-free or prevent the
pressure filter from filling with water.
• Clean the pressure filter as previously described before storing the
pressure filter.
Disposal and storage of waste
Electrical appliances that have been used in the household should be disposed of
according to EU directives. The product must not be disposed of with normal
household waste, but should be collected separately. It is your responsibility to
ensure that the device is returned to a specially designated collection point and
dismantled and processed in an environmentally friendly manner.
More information on local waste collection points can be found at your local
municipality.
No. Description
4 UV-c lamp
5 Quartz glass seal
6 Quartz glass
8 Lid
9 Filter foam set
9A) Gear plate
9B) Top plate
9C) Bottom plate
9D) Foam disk white
9E) Foam disc blue
9F) Foam disc yellow
10 Black hood
11 UV-c tube hood
12 Lid basket
13 Bio-ball
14 Basket
15 Clamping ring
16 O-ring tank
17 Tank
18 Motor
19 Inner tank
No. Description
20 BioCell
21 Grommet (model A, B or C)
22 Grommet (model A, B, C, D or E)
23 Gland (model A or C)
24 Turn rod
25 Lower bearing
26 Plate
27 Screw
28 Screw grommet
29 Lead-through
34 Valve
35 Valve ring
36 Seal kit valve
37 Control box
40 Filter cartridge top plate
41 Screw cover cap (2x)
42 Cover cap
43 UV-c cap
44 Sealing UV-c cap
45 Screw cover cap (4x)
Parts can be ordered from your dealer, indicate drawing number, description and type of
pressure filter with your order.
