AUMA Aumatic AC 01.1 Short Instructions

2
Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Profibus DP Short instructions
Scope of these instructions:
These instructions are valid for multi-turn actuators of the type ranges
SA(R) 07.1 – SA(R) 16.1 and SA(R)ExC 07.1 – SA(R)ExC 16.1
as well as for part-turn actuators of the type ranges
SG 05.1 – SG 12.1 and SGExC 05.1 – SGExC 12.1
with the controls AUMATIC AC 01.1 or ACExC 01.1
with Profibus DP interface.
Table of contents Page
1. Safety instructions 3
1.1 Range of application 3
1.2 Commissioning (electrical connection) 3
1.3 Maintenance 3
1.4 Warnings and notes 3
2. Short description 3
3. Electrical connection 4
3.1 Power supply (standard) 4
3.2 Remote position transmitter 4
3.3 AUMATIC on wall bracket 4
3.4 Fitting of the connection housing 5
3.5 Test run 5
3.5.1 Bus connection (standard) 5
3.5.2 Mains and bus connection for explosion-proof version 7
3.5.3 Bus cables 9
3.6 Setting the Profibus DP address via local controls 10
4. Redundant bus connection with component redundancy (option) 12
4.1 Settings for the redundant Profibus interface 2 (component redundancy) 12
5. Description Profibus DP interface 13
5.1 Status indications in the display 13
5.2 Assignment of the customer inputs of the Profibus DP interface (option) 14
5.3 Assignment of the Profibus DP connection 14
6. Appendix A Connection of the screen for AUMATIC ACExC 01.1 15
Addresses of AUMA offices and representatives 16

AUMA Aumatic AC 01.1 Specifications

General

Brand	AUMA
Model	Aumatic AC 01.1
Category	Control Unit
Language	English
