AUMA EPAC - Page 20

20
C
Open->FLT Rly
Close->OPT Rly
Opt-Rly Opened
YES/NO?
Opt -Rly Closed
YES/NO?
Opt -Rly Remote Local Stop
YES/NO?
Opt -Rly Local Stop
YES/NO?
Opt -Rly Open torque trip
YES/NO?
Opt -Rly Close torque trip
YES/NO?
Opt -Rly Loss of Phase
YES/NO?
Opt -Rly TH- Trip
YES/NO?
Opt -Rly TOLR Trip
YES/NO?
Opt -Rly Cntrl spl fail
YES/NO?
Opt -Rly Phase Reversal
YES/NO?
Opt -Rly Jammed Valve
YES/NO?
K
F-Rly Opened
YES/NO?
F-Rly Closed
YES/NO?
F-Rly Remote Local Stop
YES/NO?
F-Rly Local Stop
YES/NO?
F-Rly Open torque trip
YES/NO?
F-Rly Close torque trip
YES/NO?
F-Rly Loss of Phase
YES/NO?
F-Rly TH- Trip
YES/NO?
F-Rly TOLR Trip
YES/NO?
F-Rly Cntrl spl fail
YES/NO?
Phase Reversal
YES/NO?
Jammed Valve
YES/NO?
