DIAGNOSTIC MODE – Software Flowchart
NOTE: Flow-Control L of Factory Settings under
Diagnostic Mode is in the scope of Auma India
Engineers only.
Diagnostic Mode
Stop to Enter
Version Reading
Stop to Enter
Version Reading
VER: I2018-03-21
RTC Reading
Stop to Enter
RTC Reading
19/13/18 11:28
POT Reading
Stop to Enter
POT Reading
00253
4to20ma Reading
Stop to Enter
4to20ma Reading
00100
Phase Detection
Stop to Enter
Phase Detection
066 IN PHASE
Factory Reset
Stop to Enter
Factory Reset
YES/NO? NO
Factory Setting
Stop to Enter
L
Stop
Stop
Stop
Stop
Stop
Stop
Stop
Close
Close
Close
Close
Close
Close
Close
Open
Open
Open
Open
Open
Open
Open
Open
Works Number
Stop to Enter
Works Number
1818ID00025
Stop
