CONNECTION DIAGRAM 1
Speaker Terminals
Connect front speakers, a center speaker, surround speakers to 5.1 speaker
output terminals.
• The front speaker‘s cords to the FRONT SPEAKERS terminals
• The center speaker‘s cord to the CENTER SPEAKERS terminals.
• The surround speaker‘s cords to SURROUND SPEAKER terminals.
Note: Do not leave objects generating magnetism near the speakers.
