Aunex AC2000.4D - Connection Terminals

8
10. Speaker Outputs: Your AC amplier speaker outputs are
designed to accept 16 AWG to 8 AWG wire. Turn the set
screws on this terminal counterclockwise to loosen the
screws using the supplied Hex wrench. Strip the PVC jacket
from your speaker wire ½ inch (12mm). Then insert the bare
wire into the terminal block so that no bare speaker wire is
exposed. Then tighten the set screw by turning it clockwise.
Loading your amplier below the recommended
impedance rating found on page 15 is not
recommended and may cause your amplier to
enter into protection mode and may void your warranty.
For maximum current ow, Aunex recommends that you tin
your speaker wire before connecting it to the speaker output
terminals. In addition, Aunex recommends using high
quality 100% OFC (Oxygen Free Cooper) or Tinned 100% OFC
speaker wire. This will ensure that your speaker /
subwoofer receives maximum output from your amplier.
11. +12Volt Positive Terminal: The +12Volt positive terminal is
designed to accept up to 4 AWG wire. Use the supplied fuse
block and make your +12Volt connection directly to the positive
battery post. The Fuse should be installed within 18” (457mm)
of the battery. This fuse is vital to protecting the vehicle and
amplier from a dead short. Turn the set screws on this termi-
nal counterclockwise to loosen the screw using the supplied
Hex wrench. Strip the PVC jacket from your speaker wire ½
inch (12mm). Then insert the bare wire into the terminal block
so that no bare speaker wire is exposed. Then tighten the set
screw by turning it clockwise.
Side Panel Layout Continued
