10
2-WAY (Regular)
X-OVER
EQ SETTING
Balance
Setting relative volume between the left and right channels.
Fader
Setting relative volume between the front and rear speakers.
Volume limit
The choice of the value of the maximum possible volume level (3 - 40 units).
Power on vol.
The choice of the volume level when the receiver is turned on (1 - 40 units).
Subwoofer
Sub-W output - turning on / disabling the subwoofer.
Sub-W level - settings of the volume volume level.
Sub-W stereo - sabwuofer RCA output mode (Mono/Stereo).
Setting filters of low and high frequencies (FNCh and FVH). The settings of this
menu item will be different for configurations 2-WAY / 3-WAY!
Front HPF - FVF configuration (HPF) of the anterior speakers
F-HPF FRQ - cut frequency: trous (off.) / 30 / 40/50 / 60 /
70 /80 /90 /100 /120 /150 /180 /220 /250 /315 /400 /500 /630 /700 /800 Hz.
F-HPF SLOPE - the steepness of the decline: 6 / 12/18 / 24 dB per octave.
F-HPF GAIN - volume level, from -8 dB to 0 db.
Rear HPF - FVF configuration (HPF) of the rear speakers
R-HPF FRQ - cut frequency: trous (off.) / 30 / 40/50 / 60 /
70 /80 /90 /100 /120 /150 /180 /220 /250 /315 /400 /500 /630 /700 /800 Hz.
R-HPF SLOPE - the steepness of the decline: 6 / 12/18 / 24 dB per octave.
R-HPF GAIN - volume level, from -8 dB to 0 db.
Subwoofer LPF - Settings of the FNCH (LPF) and the phase of the subwoofer.
SW LPF FRQ - cut frequency: 30 /40 /50 /60 /70 / 80/90 / 100 /
120 /150 /180 /220 /250 /315 /400 /500 /630 /700 /800 Hz / Trough (excavation).
SW LPF PHASE - Switching the electric phase: 0 ° /180 °
SW LPF GAIN - volume level, from -8 dB to 0 db.
SW LPF SLOPE - the steepness of the decline: 6 / 12/18 / 24 dB per octave.
Tweeter - high frequency setting
FRQ - frequency selection: 1 / 1.6 / 2.5 / 3.15 / 4 /5 / 6.3 / 8 /10 / 12.5 kHz.
GAIN LEFT - volume level (left channel), from -8 to 0 dB.
GAIN RIGHT - volume level (right channel), from -8 to 0 db.
