Paper Shredder
Operating Instructions
Installation
Operation
Maintenance
Troubleshooting
Service Center
Warning
Limited Warranty
Sheet Capacity
Paper Shred Size
Paper Entry Width
Credit Card & CD Capacity
Voltage
12 Sheets of 20lb. bond paper*
7/32 in. x 2 5/32 in. pieces
(0.56 cm x 5.5 cm pieces)
8.7 in / 22.0 cm
1 at a time
120V~60Hz / 3.0 A
* ONE FOLDED SHEET OF PAPER EQUATES TO 2 SHEETS OF PAPER
Heavier paper, humidity or other than rated voltage may reduce sheet capacity.
INSTALLATION
Attach all 4 caster wheels to the bottom of the wastebasket.
This model will only operate if the shredder head unit is in the correct position on top of the shredder
body and used with the supplied basket. Push basket into shredder body (FIGURE 1). Position shredder
head over body.
Lift the shredder head unit by its handle and gently place over the shredder body, while aligning the
locking clips on both left and right sides. The front of the shredder head unit and the pull-out wastebasket
should be facing the same direction. Firmly push down on four corners of shredder head to lock into
position (FIGURE 2).
When completed, the head unit should be attached to shredder body and pull-out wastebasket is free
to be opened and closed. The supplied wastebasket activates this switch, which allows the shredder to
be operable. Lining the wastebasket with a plastic bag will interfere and may keep the shredder from
functioning.
FIGURE 1
FIGURE 2
FIGURE 3
INSTALLATION
Make sure the basket door is securely closed shut. This shredder features a safety power cut off and
will not operate if door is open. Shredders with pull-out wastebaskets feature a safety power cut off
upon bin removal. The supplied wastebasket activates this switch, which allows the shredder to be
operable. (FIGURE 1)
A socket-outlet should be near the equipment and be easily accessible.
Connect the power cord to any standard 120 volt AC outlet. (FIGURE 3)
Caution: Crosscut shredders have very sharp exposed blades on the underside.
Use care when mounting the shredder on the wastebasket.
CONTINUED NEXT PAGE
