Functions and Values:
DMX CHANNEL DMX VALUE SPECIFICATION
CHANNEL 1 : RED 0-255 DIM : 0 – 100%
CHANNEL 2 : GREEN 0-255 DIM : 0 – 100%
CHANNEL 3 : BLUE 0-255 DIM : 0 – 100%
CHANNEL 4 : DIMMER 0 -10
11-17
18-255
NO FUNCTION
SHUTTER CLOSED
DIMMER: 0-100%
CHANNEL 5: MACRO 000-016 NO FUNCTION
017-023 BLACK OUT
024-031 RED 70% GREEN 100% BLUE 100%
032-039 RED 100% GREEN 70% BLUE 100%
040-047 RED 100% GREEN 50% BLUE 100%
048-055 RED 100% GREEN 25% BLUE 100%
056-063 RED 100% GREEN 0 BLUE 100%
064-071 RED 70% GREEN 0 BLUE 100%
072-079 RED 50% GREEN 0 BLUE 100%
080-087 RED 30% GREEN 0 BLUE 100%
088-095 RED 0 GREEN 0 BLUE 100%
096-103 RED 0 GREEN 25% BLUE 100%
104-111 RED 0 GREEN 50% BLUE 100%
112-119 RED 0 GREEN 70% BLUE 100%
120-127 RED 0 GREEN 100% BLUE 100%
128-135 RED 0 GREEN 100% BLUE 70%
136-143 RED 0 GREEN 100% BLUE 50%
144-151 RED 0 GREEN 100% BLUE 25%
152-159 RED 0 GREEN 100% BLUE 0
160-167 RED 25% GREEN 100% BLUE 0
168-175 RED 50% GREEN 100% BLUE 0
176-183 RED 70% GREEN 100% BLUE 0
184-191 RED 100% GREEN 100% BLUE 0
192-199 RED 100% GREEN 80% BLUE 0
200-207 RED 100% GREEN 60% BLUE 0
208-215 RED 100% GREEN 40% BLUE 0
216-223 RED 100% GREEN 30% BLUE 0
224-231 RED 100% GREEN 20% BLUE 0
232-239 RED 100% GREEN 10% BLUE 0
240-247 RED 100% GREEN 0 BLUE 0
248-255 RED 100% GREEN 100% BLUE 100%
CHANNEL 6 : EFFECT 0 -5
06 -35
36 -65
66 –95
96 –125
126 –155
156 –255
186--215
216--245
246--250
251--255
NO FUNCTION
STROBE SPEED
PAUSE STROBE
EFFECT COLOR FADE STROBE
COLOR CHANGING
COLOR FADE DIMM IN THAN DIMM OUT
COLOR FADE SHUTTER OPEN THAN DIMM OUT
COLOR FADE SHUTTER CLOSE THAN DIMM IN
COLER FADE RAINBOW EFFECT
SOUND ACTIVATION MODE 1
SOUND ACTIVATION MODE 2
