C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
100
Engine oil: Draining (fig. 1, 2)
The oil change should be made when the oil is warm.
WARNING
The engine oil may be very hot. To avoid the risk of burns, do not remove the
drain plug or unscrew the filter if the engine is hot. Wait until the engine oil is
cooler.
- Make sure the forklift is on level ground.
- Remove the dipstick.
- Clean the area around the oil drain plug.
- Place a container below the oil drain plug.
- Unscrew the oil drain plug.
- Allow all the oil to drain from the engine.
- Clean the oil sump drain plug and replace the plug with a new plug.
- Screw on the plug by hand and tighten it.
Oil filter cartridge: Replacing (fig. 3, 4)
The oil filter cartridge (a) is located on the left-hand side of the engine.
- Unscrew the oil filter cartridge by turning to the left.
- Clean the base of the filter and oil the seal of the new filter element.
- Screw on the new filter element and tighten by hand, without using mechanical
means.
Dispose of the used oil filter cartridge in an authorized centre for this purpose.
(fig. 4) Kubota V3600 (fig. 3) Kubota 2403-M (fig. 1) Kubota 2403-M
(fig. 2) Kubota V3600
Periodic
Maintenance
Operations
a
a
