AUSA C300H - Page 48

C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
46
Decals / labels / identification plates all markets (except USA)
STICKER:
CHARACTERISTICS PLATE
REFERENCE: DESCRIPTION: QUANTITY:
01.00779.26 PLATE CHARACTERISTICS 100x130 1
POSITION:
Riveted on top of the engine bulkhead, on its rear upper left-hand side (in
forward direction of machine), in the holes prepared. Etched according to
assembly instruction.
STICKER:
AUSA ANAGRAM
REFERENCE: DESCRIPTION: QUANTITY:
46.08099.00 AUSA ANAGRAM 1
POSITION:
Embedded in the cab front panel, on its outer side, in the upper left-hand part
(in forward direction of machine).
STICKER:
WARNING IN CASE OF OVERTURNING THE MACHINE
REFERENCE: DESCRIPTION: QUANTITY:
12.12010.00 SAFETY STICKER 1
POSITION:
Top left-hand corner of the dashboard, under sticker ref. 02.00774.00 “Do not
use” and aligned with this on its left side.
