C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
47
Decals / labels / identification plates all markets (except USA)
STICKER:
ACOUSTIC OPERATOR PROTECTION
REFERENCE: DESCRIPTION: QUANTITY:
01.00757.00 INDICATIVE STICKER D40 1
POSITION:
Top left-hand corner of the instrument panel, under sticker 02.00774.00 “Do not
use”, aligned with this on its right side and centered with sticker ref. 12.12010.00.
STICKER:
POINT HOISTED MACHINE
REFERENCE: DESCRIPTION: QUANTITY:
09.15720.00 INDICATIVE STICKER 35x35 4
POSITION:
Above each of the four eyebolts at the bottom of the frame for lifting the machine.
STICKER:
MAXIMUM SOUND LEVEL
REFERENCE: DESCRIPTION: QUANTITY:
09.12014.00 STICKER NOISE 104 DB 1
POSITION:
On the inside of the right front wheel arch, aligned with the cab floor.
