C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
92
By-passing the hydrostatic pump (fig. 1)
The forklift towing is only recommended when there is no other option during a break-
down so the hydrostatic transmission can be seriously damaged. Whenever is possible
it is recommended fixing in the place where is stopped. Otherwise, towing should only
occur over short distances and at low speed. Comply with all state laws governing the
operation / towing of an off-highway machine on public roads and highways.
CAUTION
It is possible to damage the drive motor by operating in bypass mode without
charge pressure. Move the forklift at a speed not more than 20% of maximum
for a duration not exceeding 3 minutes.
Use this procedure to bypass the pump to allow moving the forklift short distances when
you cannot start the engine.
To open the by-pass valves, screw-in (but not over-tight them) the centre screws of he
hydrostatic pump safety relief valves. To do so, loose the counter-nuts.
Once the machine is fixed, screw-out again the hydrostatic pump safety relief valves
tight the counter-nuts again.
(fig. 1)
Transporting
the machine
