Dynamic Series
Part A: Description, warnings and instructions
Working
A - 22
6.7.1 Description
The wire control connects the transmitting unit to the receiving unit through a ca-
ble that replaces the radio link. The cable shall be plugged in the suitable connec-
tors, one on the transmitting unit and the other on the receiving unit (or placed
where established by the machine manufacturer).
When using the wire control, the working features do not change (i.e. the mean-
ing of actuators and the Data Feedback function).
6.7.2 Operation
Before starting to work, make sure that the cable and the corresponding connec-
tors are intact.
The wire control can only be connected and disconnected when the transmitting
unit is switched off.
After connecting or disconnecting the wire control, start up the radio remote con-
trol (see paragraph 5.1) to control the machine.
During operation with wire control:
- radio link is off
- leave the battery inside the transmitting unit, even though the power supply
comes from the receiving unit.
The battery is not, in any case, recharged through the wire control: it can only
be recharged through its appropriate battery charger provided together with
the system.
When you finish working with the wire control, disconnect the cable from the
transmitting unit and from the machine, and protect the connectors with their
caps.
