22) Press Y button and following screen shows:
23) Actuate the pedal gently to raise the pressure to 20-24 bar and
keep it for 5s.
24) Follow onscreen instructions to complete operation of current
phase:
- The fill level of wheel brake circuit HZ2 (secondary brake
circuit) is in order.
- Release brake pedal.
- Checking fill status of wheel brake circuit HZ1 (primary brake
circuit).
25) Press Y button or gently actuate and then release the pedal to
continue, and the device starts to communicate with the vehicle.
26) Use UP/DOWN button to view onscreen prompts
prompt screens to be continued…
........ Inspect Brake Air .... .
11.8 bar
0 25
↑
Hold pressure within
black range for 5s.
........ Inspect Brake Air .... .
3/3
be within the black
range and be held
for 5s.
5. [Y] =Con. [N] =Return
........ Inspect Brake Air .... .
1/3
1. Increase brake
pressure slowly and
evenly.
2. At 10 bar the brake
pedal counterforce
is reduced but
To Next Page
