34
Figure 4.23
NOTE: The sensor writing procedure may vary for different
vehicles being serviced. Please follow the onscreen instruction
and take appropriate measures and selections to complete the
process.
NOTE: If there are untested sensors in the vehicle, the writing ID
process cannot proceed. The tool will display a warning message
as below. In this case, follow the sensor check procedure to
activate all sensors in vehicle and register sensor IDs again.
Figure 4.24
NOTE: If duplicate IDs present, the writing ID process cannot
proceed. In this case, follow the sensor check procedure to
activate all sensors in vehicle and register sensor IDs again.
IMPORTANT: Make sure to turn the ignition off before
connecting/disconnecting the OBD II Cable to/from the TPMS tool;
otherwise it may cause the Malfunction Indicator Light (MIL) to
