37
Figure 4.28
4.3 Review Data
The Review Data function allows user to view and print out saved data
of the latest TPMS diagnostic recordings by the service tool.
Use the UP/DOWN and LEFT/RIGHT scroll button to select Review
Data from Main Screen (Figure 3.1), and wait for the review data
menu to appear.
Figure 4.29
NOTE: If no data from the previous TPMS diagnosis is recorded,
a message “No data available!” will show on the screen.
1) Use the UP/DOWN scroll button to select the desired stored data
(taking Read IDs from Vehicle as an example) from review menu
and press the Y button.
2) A list of retrieved sensor IDs will show on the screen.
