6. Diagram
1.Left Control Stick
2.Gimbal Pitch Dial
3.Customizable Button
4.Chest Strap Hook
5.Air Outlet
6.USB-A Port
7.USB-C Port
8.Micro-SD Card Slot
9.HDMI Port
10.Record/Shutter Button
11.Zoom Control Wheel
12.Right Control Stick
4
4 5 6
9
8
11
3
10
2
4
1
12
maximum operating time of about 3 hours
[2].
[1] In an actual flight environment, the maximum transmission
range may be less than this nominal distance and will vary with
the interference strength.
[2] The above-mentioned operating time is measured in a lab
environment at room temperature. The battery life will vary in
different usage scenarios.
7
